Product Specifications
|
Model No.
|
HL162-40W
|
HL162-60W
|
HL162-80W
|
||||
|---|---|---|---|---|---|---|---|
|
Configuration
|
standard model
|
microwave model
|
standard model
|
microwave model
|
standard model
|
microwave model
|
|
|
Dimensions
|
611*106*82mm
|
669*106*92mm
|
611*106*82mm
|
669*106*92mm
|
611*106*82mm
|
669*106*92mm
|
|
|
Luminous efficiency
|
150±10Lm/W
|
||||||
|
Luminous flux
|
6000±400LM
|
9000±600LM
|
12000±800LM
|
||||
|
Color temperature
|
3000K;4000K;5000K;5700K
|
||||||
|
Protection grade
|
IP66
|
||||||
|
IK grade
|
IK10
|
||||||
|
Wind resistance grade
|
12
|
||||||
|
Color rendering index
|
Ra > 70
|
||||||
|
Beam angle
|
30X70°、40X130°、60°、60X90°、90°
|
||||||
|
Input voltage
|
AC120V-277V
|
||||||
|
Power factor
|
＞0.9
|
||||||
|
Frequency
|
50Hz/60Hz
|
||||||
|
Power supply type
|
constant current
|
||||||
|
Net weight of lamps
|
2.9KG
|
3KG
|
2.9KG
|
3KG
|
2.9KG
|
3KG
|
|
|
Packaging Information
|
1PCS/CTN
|
||||||
|
Carton size
|
74.3cm*17.0cm*14.8cm
|
||||||
|
Gross weight
|
3.7KG
|
3.8KG
|
3.7KG
|
3.8KG
|
3.7KG
|
3.8KG
|
|
|
Pull in sealing ring through
wire diameter size
|
Φ8mm-Φ14mm
|
||||||
|
Cable entry thread
|
M25×1.5
|
||||||
|
Installation method
|
Side wall installation, ceiling installation, hoop installation
|
||||||
|
Material
|
Main body
|
6063-T5、ADC12
|
|||||
|
Optics
|
lens+PC
|
||||||
|
Appearance color
|
silver gray
|
||||||
|
Service life
|
50000 hours
|
||||||
|
Warranty
|
5 years
|
||||||
|
Explosion-proof signs
|
Ex nR IIC T6 Gc; Ex tb IIIC T80°C Db(EX db nR IIC T6 Gc; Ex tb IIIC T80°C Db)
|
||||||
